Horizontal CNC Lathe
Have one to sell?
ConditionNew
New
Specifically designed for medium and small sized workpieces
High rigidity complete box way slide structure design
Power turret and C-axis design satisfies the machining demand of hybrid milling and turning
Patented automatic material feed and storage device, the time for material feeing and return can completed by a minimum of 4.8 seconds
Chuck O.D. 6" (8") inch
Bar capacity Ø26 (Ø44) (Ø51) mm
X/Z axis travel 155/220 mm
X/Z axis rapid traverse Box way 20/20 m/min
Spindle nose A2-5 (A2-6)
Spindle speed 6,000 (4,800) (4,500) rpm
Spindle motor 15/11/7.5 [18.5/15/11] kW
Tool capacity 12 (8) [VDI-40：12] pc
