Meeting process integration needs from material to product
Have one to sell?
ConditionNew
New
Supporting automation needs
The ability to mount a new gantry loader allows flexible configuration of automation lines for flange workpieces.
Improved capability suited to bar work
A higher motor output power in addition to a larger main spindle through-hole diameter increases the cutting capacity, allowing heavy-duty cutting of large-diameter bar materials. (Maximum bar diameter for main spindle: φ51 mm, motor output: 18 . 5 / 15 / 11 k W, 13% reduction in spindle acceleration/deceleration time and 50% increase in material removal compared to existing machines)
φ51 Through-hole, BMT45 type
Main-spindle Sub-spindle
Chuck size Collet, 6 inch
Spindle
- Spindle bearing I.D. φ100 φ85 mm
- Spindle speed Max. 5,000 min-1
Tool post
- Type 12-station Turret 24st. BMT45
-Max.stroke X1:162.5 Z1:500 Y:±35 X2:170 Z2:500 A:550 mm
-Rapid traverse rate X:18 Z:30 Y:12 A:30 m/min
Power tools
- Tool storage capacity 12 pcs.
- Rotation speed 4,000 min-1
- Capabilities φ13 M12 mm
Spindle motor AC18.5 / 15 / 11 AC11 / 7.5 / 5.5 kW
W × L 2,988×2,163 mm
Controller TAKAMAZ & FANUC 32i-B
φ65 Through-hole, BMT55 type
Main-spindle Sub-spindle
Chuck size Collet, 8 inch
Spindle
- Spindle bearing I.D. φ120 φ100 mm
- Spindle speed Max. 4,000 min-1
Tool post
- Type 12-station Turret 24st. BMT55
- Max.stroke X1:162.5 Z1:500 Y:+40-35 X2:170 Z2:500 A:550 mm
- Rapid traverse rate X:18 Z:30 Y:12 A:30 m/min
Power tools
- Tool storage capacity 12 pcs.
- Rotation speed 4,000 min-1
- Capabilities φ20 M16 mm
Spindle motor AC18.5 / 15 / 11 AC9 / 7.5 / 5.5 kW
W × L 3,000×2,163 mm
Controller TAKAMAZ & FANUC 32i-B
