Upgraded machine with expanded tool capacity and greater workpiece size
Have one to sell?
ConditionNew
New
10-station turret equipped as standard
Two 10-station turrets are installed to increase the number of tools that can be accommodated for better production efficiency.
Longest stroke in the two-spindle series
Slide strokes of 170 mm on the X axis and 270 mm on the Z a xis achieve the maximum O.D. turning zone in the TAKAMAZ two-spindle series. Even workpieces that require cutting deep into the I.D. at the same time, such as differential cases and brake calipers, can be handled.
Chuck size Collet, 10×2 inch
Spindle
- Spindle bearing I.D. φ120 mm
- Spindle speed Max. 2,800(4,000 Opt.) min-1
Tool post
- Type 10-station turret × 2
- Max.stroke X:170, Z:270 mm
- Rapid traverse rate X:24, Z:24 m/min
Spindle motor AC18.5 / 15 ×2 kW
W × L 2,030 (2,350 ※) × 2,370 mm
Controller TAKAMAZ & FANUC 0i-TF
