Compact. Universal. Economical.
The machine version that agrees all the advantages of the FZU22, for large-volume components. Aluminum, plastics and wood are their métier, as is the finishing of CFRP parts (carbon fiber and composites). The top-moving gantry also ensures high precision in the production of models and molded parts. The standard version includes the tool changer for 12 tools and a control of the latest generation (Siemens or Heidenhain). The specially developed 5-axis milling head with 15 kW spindle is also suitable for machining hard-to-reach workpiece locations due to its geometry. Customer requirements can be met individually with regard to the design of the machine table.
Working Ranges
X-Axis 3 000/4 000/5 000 mm (118"/157"/197")
Y-Axis 3 000/3 500 mm (118"/138")
Z-Axis 1 250/1 500 mm (49"/59")
Drives Linear Axes
Feed rate X-, Y-Axis up to 70 m/min (2755 ipm)
Feed rate Z-Axis up to 40 m/min (1574 ipm)
Acceleration X-, Y-, Z-Axis max. 3 – 5 m/s² (118-197 in/s²)
Dimensions
Required space (without peripherals)
Length
5 630 – 6 630 mm (221"-261")
Width
5 840 – 6 340 mm (230"-250")
Height
4 400 – 4 650 mm (173"-183")
Accuracy
Standard
in accordance to VDI/DGQ 3441 or ISO 230-2
