Wide Flange/Bundle Saw
Have one to sell?
ConditionNew
New
The WF1827M band saw is designed to cut structural shapes and bundles efficiently using a fixed 9.2ᵒ canted blade. Operated with a touch-screen control mounted in a swing-away console it includes a full-stroking bi-directional main vise. Many options are available including additional top clamps and outboard vise.
Standard Features
Swing-Away Console - Semi-Automatic Control
24" Roller Discharge Table
Vise - Full Stroking Bi-Directional Main
Adjustable Clamping Force
Arm Cant - 9.2° Permanent
Carbide Blade Guides
Lead In/Lead Out Roller Guides
Guide Arm - Powered
Variable Blade Speed w/ Readout on Touch Screen
Adjustable Feed Rate
Adjustable Cutting Pressure
Powered Blade Tension
Coolant System - Flood w/ Wash-Down Hose
Two-Hand Operation Controls
Blade Brush
Broken Blade Function
Automatic Blade Idle
Blade Change Interlock
Safety Guards
220V/3PH or 440V/3PH Electrical Motor Requirement - This is Not a Dual Voltage Machine
Rectangular Capacity 0-27" W x 0-18" H
Square Capacity 0-18" (Square)
Round Capacity 0-18" (Diameter)
Bar-feed N/A
Motor 10 HP
Hydraulic Motor 5 HP
Operation Type Semi-Automatic
Power Source Hydraulic
Weight N/A
Blade Type Bandsaw
Blade Size 21' 0" L x 1.5" H x .050"
Cantilever Fixed
Bandsaw Blade Speed N/A
Bundle Cut? Yes
